New RollerFORM™ XL Phased Array Scanner Provides More Than Twice the Coverage

WALTHAM, Mass., (January 12, 2021)—Olympus’ new RollerFORM™ XL scanner answers the demand for a wide-coverage and easy-to-implement phased array tool to accelerate the inspection of composite components with large surface areas.

In the aerospace and wind energy industries, critical components such as aircraft wings and wind turbine blades are made with lightweight, durable composite material. Inspectors use nondestructive testing technology to ensure the integrity of these parts, both before they are assembled and for in-service maintenance. Ultrasonic testing is a standard method, but the parts’ extensive surface areas, the attenuative nature of composite and the complicated operation of some ultrasonic testing equipment can cause problems. The new RollerFORM XL scanner is an innovative and easy-to-use phased array wheel probe that helps resolve these issues.

Scans Large Parts in Less Time

Based on the field-proven design and performance of the original RollerFORM scanner, the RollerFORM XL scanner’s tire with integrated phased array probe provide a beam coverage that is twice as wide. Scanning large parts is more efficient and the data’s accuracy is improved since the wider beam coverage also increases the probability of detection.

Minimal Setup, Simple Operation

Light and easy to operate, the RollerFORM XL scanner takes minimal effort to set up and inspect compared with immersion-based testing. Strong, reliable signals are obtained without a couplant pumping system thanks to the scanner’s innovative tire. Interface reflections are minimized because the tire is filled with liquid and the material has an acoustic impedance that closely matches water. This similarity enables the ultrasound beam energy to transmit efficiently into the part.

Optimized for Composite Inspection

Beam penetration is optimized in attenuative composite materials because of the RollerFORM XL scanner’s optional low-frequency, large-elevation phased array probe. Inspectors can easily integrate this new wider model into existing wheel probe procedures. The RollerFORM XL scanner also has an encoder, an indexing button and a start acquisition button to facilitate complete scans of large wings or blades.

With minimal setup, inspectors can implement this self-contained wheel probe system to not only save time, but also improve the accuracy of their results.
